Tank longitudinal seam welding machine

1. Introduction

●The device is composed of welding host machine and control system, there is a cableconnected into an complete machine through the host machine and control system,convenient to install and commission and some other work.

● Standard welding machine mainly composed of main frame, key press typepneumatic fixture, welding core shaft, shaft bracket, gun running mechanism, liftingmechanism, the torch of pneumatic mechanism, a welding torch adjusting mechanism
and pneumatic control system and other components.

2. Technical parameters

Item	ZFH-1000	ZFH-1500	ZFH-2000	ZFH-3000
Tank welding length	≤1000mm	≤1500mm	≤2000mm	≤3000mm
Tank welding diameter	100-750mm	120-750mm	160-750mm	250-750mm
Wall thickness	0.5-5.0mm
Welding torch movement speed	200-2000mm/min
Welding torch lift stock	200mm
Welding torch micro-adjust stock	Y/ Z=100mm

●Before the welding work-piece spot welding for firm, clean solder joints, fixed arcstrike and arc stop plate
