No.

Item

Specification

1

Web height

200-1500mm

2

Web thickness

6-14mm (if web thickness ≥14mm, weld is acceptable but can not melt through)

3

Flange width

200-800mm

4

Flange thickness

6-20mm

5

H beam length

4000-15000mm

6

Welding speed

350-1500mm/min

7

Welding way

Single arc single wire

8

Welding wire diameter

3.2 or 4.0mm

9

Web positioning

Hydraulic motor + gear * screw lead wheel

10

Flange clamp

Hydraulic motor + gear * screw lead wheel

11

Control

AC frequency control

12

Conveyor

3+1 pieces of input conveyor (two of them is motorized)

3 pieces of output conveyor (two of them is hydraulic lift)

13

Pull rod

1 piece, hydraulic driven

14

Hydraulic station

5.5KW

15

Transmission motor

4KW

16

Conveyor motor

1.1KW * 2

17

Flux machine capacity

3KW * 2

18

SAW welder power

69KVA * 2

19

Voltage

AC380V 50HZ 3P or customized
